MF52D小皮线NTC热敏电阻选型表
| 部件号 | 电阻 @25C | 贝塔值 |
| R25 （欧姆） | (K) | |
| MF52D-102□3950 | R25: 1 K 欧姆 | B(25/50C): 3950 k |
| MF52D-202□3470 | R25: 2 K 欧姆 | B(25/50C): 3470 k |
| MF52D-202□3550 | R25: 2 K 欧姆 | B(25/50C):3550 k |
| MF52D-202□3950 | R25: 2 K 欧姆 | B(25/50C):3950 k |
| MF52D-2252□3935 | R25: 2252 欧姆 | B(25/50C):3935 k |
| MF52D-2.78K□3950 | R25: 2.78 K 欧姆 | B(25/50C):3950 k |
| MF52D-302□3977(B25/85) | R25:3K 欧姆 | B(25/85C):3977 k |
| MF52D-332□3950 | R25: 3.3 K 欧姆 | B(25/50C):3950 k |
| MF52D-472□3950 | R25: 4.7 K 欧姆 | B(25/50C): 3950 k |
| MF52D-502□3470 | R25: 5 K 欧姆 | B(25/50C): 3470 k |
| MF52D-502□3950 | R25: 5 K 欧姆 | B(25/50C): 3950 k |
| MF52D-682□3977(B25/85) | R25: 6.8 K 欧姆 | B(25/85C): 3977 k |
| MF52D-682□4200 | R25: 6.8 K 欧姆 | B(25/50C): 4200 k |
| MF52D-103□3380 | R25: 10 K 欧姆 | B(25/50C): 3380 k |
| MF52D-103□3435(B25/85) | R25: 10 K 欧姆 | B(25/85C): 3435 k |
| MF52D-103□3470 | R25: 10 K 欧姆 | B(25/50C):3470 k |
| MF52D-103□3950 | R25: 10 K 欧姆 | B(25/50C): 3950 k |
| MF52D-103□3977(B25/85) | R25: 10 K 欧姆 | (B25/85 C): 3977 k |
| MF52D-103□4100 | R25: 10 K 欧姆 | B(25/50C): 4100 k |
| MF52D-153□3950 | R25: 15 K 欧姆 | B(25/50C): 3950 k |
| MF52D-203□3950 | R25: 20 K 欧姆 | B(25/50C): 3950 k |
| MF52D-233□4200 | R25: 23 K 欧姆 | B(25/50C): 4200 k |
| MF52D-303□3950 | R25: 30 K 欧姆 | B(25/50C): 3950 k |
| MF52D-40.27k□3979(B25/85) | R25: 40.27 K 欧姆 | B(25/85C): 3979 k |
| MF52D-473□3950 | R25: 47 K 欧姆 | B(25/50C): 3950 k |
| MF52D-503□3950 | R25: 50 K 欧姆 | B(25/50C): 3950 k |
| MF52D-503□3990 | R25: 50 K 欧姆 | B(25/50C): 3990 k |
| MF52D-503□4050 | R25: 50 K 欧姆 | B(25/50C): 4050 k |
| MF52D-104□3950 | R25: 100k 欧姆 | B(25/50C): 3950 k |
| MF52D-104□3990 | R25:100K 欧姆 | B(25/50C): 3990 k |
| MF52D-104□4200 | R25:100K 欧姆 | B(25/50C): 4200 k |
| MF52D-154□4370(B25/85) | R25: 150 K 欧姆 | B(25/85C): 4370 k |
| MF52D-105□4730 | R25:1000K 欧姆 |
B(25/50C): 4730 k |
